What We Should Mention to Install Solar Road Stud

2022-09-20

0 views times

Share us:

The solar road stud maintain a charge adequate for full duty cycle. These solar road studs are re-charged by sunlight, lower level light, and from other light sources such as vehicle headlights. NOKIN solar road studs include a one year warranty and have a service life of up to several years.

The LED solar road stud on highway is a kind of lamp which uses solar cell as energy. The LED solar road stud on highway can emit light actively, which is better than the traditional reflective road stud. The LED solar road stud on highway can automatically control the switch of the lamp according to the intensity of the ambient light.

Some NOKIN LED solar road stud on highway models have lasted well ‘off-road’, and are still working for over 5 years now. We are trialling new solar road stud models that have been improved and are working with a few manufacturers on improving these LED solar road stud on highway.

What we should mention when install solar road stud? The surface of the position where the active solar road stud is installed shall be cleaned. Dip about 30-40g glue with a screwdriver and apply it on the back of the active solar road stud. The installation steps are as follows: firstly, put the wire of the active solar road stud through the side wall of the cable trench (pre punched hole) and put it at the fixed position. Install self tapping on the active solar road stud and tighten both sides at the same time with a cross screwdriver.

It is forbidden to install active solar road studs (easy to fall off) in places with water, moisture and oil pollution. Evacuate the road cone 4 hours after installation. Prevent the newly installed solar road stud from being damaged.

info@nk-roadstud.com

+86-13602600950

Previous: Improvements of the Solar Road Stud

Next: Most Trusted Solar Road Stud Brand–NOKIN

Inquiry

If you have any question or comment, please contact us without hesitation. We will reply you as soon as possible.( * is required information)

*Name:; *Email:; Phone:; Company:; Country:; *Message:

Hot Products

NOKIN Amber Raised Solar Road Stud Light For Expressway NK-RS-A6-1

2020-05-18

Body material: Aluminum(GB-ADC12)+PC(Japan Brand)
Power supply: USA Brand High Efficient Solar Panel
Battery: NI-MH1.2V/600MAH; Lithium battery3.2V/500MAH(Made in Japan);
Resistance: >30T
LED Color: White, Yellow, Blue, Red, Green
Size: L125mm*W107mm*H26+50mm

Heavy Duty Solar Road Stud For Sale NK-RS-X5

2020-05-18

Body material: Casting Aluminium alloy +PC
Power supply: 5V/80MAH Mono crystalline silicon
Battery: Lithium battery3.2V/1000MAH
Resistance: >40T(can be installed in the middle of road)
LED Color: White, Yellow, Blue, Red, Green
Size: φ125*50mm

Round PC Solar Road Stud Light NK-RS-K1

2020-05-18

Body material: PC
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NIMH 600MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: φ117*23mm

Ultra Thin PC Solar Road Stud Light For Road NK-RS-Q7

2020-05-18

Body material: PC
Power supply: High efficient solar panel(5V/60mA)
Battery: Lithium battery(3.2V/500mAh)
Resistance: 15T
LED Color: White, Yellow, Blue, Red, Green
Size: 114*90*11mm

Nokin Solar Road Stud For Sale NK-RS-D1

2020-05-18

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH or lithium battery
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L104*W104*H20mm

Yellow Flashing Aluminum Raised Solar Cat Eyes Road Stud On Road NK-RS-A6

2020-05-18

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH1.2V/800MAH
Resistance: >20 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: L123*W133*H22mm+55mm

Internally Illuminated Solar Pavement Levelled Markers Studs NK-RS-X6

2020-05-18

Body material: Aluminum Alloy+PC cover
Power supply: Solar panel(Monocrystalline 2.5V /120MA)
Battery: Lithium battery 1000MAH*3.2V
Resistance: >30 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: Ф123*45mm

6 LED Embedded Solar Road Marker Light Supplier In China NK-RS-A10

2020-05-18

Body material: Cast Aluminum
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >30 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: Ф120*50mm（bottom）
Ф135*50mm（upper）

Colorful Aluminum Solar Road Stud Light For Road NK-RS-A6-2

2020-05-18

Body material: Heavy duty casting aluminium
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L129*W114*H23mm+53mm

China Aluminuim Solar Road Stud Light For Sale With Best Price NK-RS-T1

2020-05-18

Body material: Aluminum+PC
Power supply: Mono crystalline solar panel
Battery: NI-MH 1.2V/ 600mah(high temperature resistance);
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: 125*43*30mm

Colorful Glass Solar Road Stud Cheap Price in China NK-RS-A7

2020-05-18

Body material: Tempered Glass/PC
Power supply: USA Brand High Efficient Solar Panel
Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH1.2V/600MAH(high temperature resistance, made in China)
Lithum battery3.2V/500MAH(made in Japan)
Resistance: >20T
LED Color: White, Yellow, Blue, Red, Green
Size: φ112*56mm

Aluminium Solar Powered Road Studs For Sale NK-RS-A1

2020-05-15

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L104mm*W94mm*H20mm
