Precautions for Installing Active Solar Road Studs

2021-08-17

0 views times

Share us:

The surface of the position where the active solar road stud is installed shall be cleaned. Dip about 30-40g glue with a screwdriver and apply it on the back of the active solar road stud. The installation steps are as follows: firstly, put the wire of the active solar road stud through the side wall of the cable trench (pre punched hole) and put it at the fixed position. Install self tapping on the active solar road stud and tighten both sides at the same time with a cross screwdriver.

Clean and maintain the active solar road stud after installation. After the installation of active solar road stud, scrape and clean the glue overflowing around the active solar road stud with a batch knife.

In addition, after the installation of the active solar road stud, it needs to be connected to the main line arranged in advance. After connecting the control box, use a universal meter to test whether there is a short circuit. If there is no problem, connect the active solar road stud to the main power. The solar panel of the active solar road stud is placed outside the tunnel where it can be exposed to direct sunlight. All active solar road studs are controlled by a main board, synchronous switch.

Precautions for installing active solar road studs: do not touch the vicinity of active solar road studs, and avoid glue sticking to the shell of active solar road studs and affecting the luminous effect!

It is forbidden to install active solar road studs (easy to fall off) in places with water, moisture and oil pollution. Evacuate the road cone 4 hours after installation. Prevent the newly installed solar road stud from being damaged.
